ZY105旋挖钻机ZY105 Rotary drilling rig
| 主要参数(Main parameter) | 单位(Units) | 参数(Parameters) | |||||
| 底盘 Chassis | |||||||
| 发动机型号 Diesel engine model | Cummins-F3.8 | ||||||
| 发动机功率/转速/阶段 Rated power/speed/stage | kW/rpm | 90/2200/Ⅴ | |||||
| 履带展开宽度（外边距）Track width(margin) | mm | 2600 | |||||
| 履带宽度 Shoe width | mm | 600 | |||||
| 液压动力头Hydraulic rotary head | |||||||
| 最大输出扭矩 Max torque | kN•m | 105 | |||||
| 动力头转速 Rotation speeds | rpm | 0-45 | |||||
| 最大加压力 Max crowd force | kN | 105 | |||||
| 最大起拔力 Max extraction force | kN | 105 | |||||
| 加压行程 Cylinder stroke | mm | 8000 | |||||
| 主卷扬 Main winch | |||||||
| 最大提升力 Max winch line pull | kN | 115 | |||||
| 最大提升速度 Max line speed | m/min | 50 | |||||
| 钢丝绳直径 Rope diameter | mm | Φ20 | |||||
| 副卷扬 Auxiliary winch | |||||||
| 最大提升力 Max winch line pull | kN | 50 | |||||
| 最大提升速度 Max line speed | m/min | 30 | |||||
| 钢丝绳直径 Rope diameter | mm | Φ16 | |||||
| 作业倾角 Mast rake | |||||||
| 桅杆前倾斜角度 Max forward tilt angle of the mast | ° | 5 | |||||
| 桅杆左右倾斜角度 Max left and right tilt angle of the mast | ° | ±4 | |||||
| 液压系统 Hydraulic system | |||||||
| 最大工作压力 Max working pressure | MPa | 32 | |||||
| 钻孔 Drilling dimensions | |||||||
| 钻孔直径 Drilling diameter（along mast） | mm | 400-1000 | |||||
| 最大深度 Max depth | m | 30 | |||||
| 主机 Machine host | |||||||
| 工作状态整机重量 Total working weight | t | 30 | |||||
| 运输状态（长×宽×高）Transport dimensions(L*W*H) | mm | 13100x2600x3420 | |||||
| 作业状态（长×宽×高）Working dimensions(L*W*H) | mm | 5860x3400x13300 | |||||
| 钻杆Drill pipe (可选配不同长度和节数Optional different length and section) | |||||||
| 型号Model | 规格Spec | 深度Depth | 重量Weight | 长度Length | 方头Stub | ||
| 摩阻杆 Friction kelly | ⌀299-4-8.5 | 30m | 3.5t | 9.5m | 150*150mm | ||
| 机锁杆 Locking kelly | ⌀299-4-8.5 | 30m | 3.5t | 9.5m | 150*150mm | ||
